Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 337
Metering and Diagnostics Chapter 8
Table 424 - Total Apparent Power (Parameter 75)
L1 Power Factor
L1 Power Factor (Parameter 76) reports the power factor for line 1 in percentage.
When Voltage Mode (Parameter 352) is set to any Delta base setting, L1 Power
Factor is set to 0.
Table 425 - L1 Power Factor (Parameter 76)
L2 Power Factor Power
L2 Power Factor (Parameter 77) reports the power factor for line 2 in percentage.
When Voltage Mode (Parameter 352) is set to any Delta base setting, L2 Power
Factor is set to 0.
Table 426 - L2 Power Factor (Parameter 77)
L3 Power Factor
L3 Power Factor (Parameter 78) reports the power factor for line 3 in percentage.
When Voltage Mode (Parameter 352) is set to any Delta base setting, L3 Power
Factor is set to 0. When Single or Three Phase (Parameter 176) is set to Single
Phase, L3 power factor is set to 0.
Default Value 0.000
Minimum Value 0.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVA or MVA
Default Value 0.0
Minimum Value -100.0
Maximum Value 100.0
Parameter Type INT
Size (Bytes) 2
Scaling Factor 10
Units %
Default Value 0.0
Minimum Value -100.0
Maximum Value 100.0
Parameter Type INT
Size (Bytes) 2
Scaling Factor 10
Units %
