Rockwell Automation Allen-Bradley E300

316 Rockwell Automation Publication 193-UM015D-EN-P - February 2015
Chapter 8 Metering and Diagnostics
Device Status 1
Device Status 1 (Parameter 21) reports the specific features of the E300
Electronic Overload Relay Control and Sensing Modules, it reports which
Expansion Digital Modules Analog Modules are present on the E300 Electronic
Overload Relay Expansion Bus.
Table 371 - Device Status 1 (Parameter 21)
Firmware Revision Number
Firmware Revision Number (Parameter 22) reports the firmware revision
number of the E300 Electronic Overload Relay system.
Table 372 - Firmware Revision Number (Parameter 22)
Control Module ID
Control Module ID (Parameter 23) identifies which specific Control Module is
present in the E300 Electronic Overload Relay system.
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X 24V DC Control Module Present
X 120V AC Control Module Present
X 240V AC Control Module Present
X 0.5…30 A Sensing Module Present
X 6…60 A Sensing Module Present
X 10…100 A Sensing Module Present
X 20…2000 A Sensing Module Present
X Digital Module 1 Present
X Digital Module 2 Present
X Digital Module 3 Present
X Digital Module 4 Present
X Analog Module 1 Present
X Analog Module 2 Present
X Analog Module 3 Present
X Analog Module 4 Present
Reserved
Default Value 0.000
Minimum Value 0.000
Maximum Value 65.535
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1000
Units
