Metering and Diagnostics Chapter 8
Table 373 - Control Module ID (Parameter 23)
Sensing Module ID
Sensing Module ID (Parameter 24) identifies which specific Sensing Module is
present in the E300 Electronic Overload Relay system.
Table 374 - Sensing Module ID (Parameter 24)
Operator Station ID
Operator Station ID (Parameter 25) identifies which specific Operator Station is
present on the Expansion Bus of the E300 Electronic Overload Relay system.
Default Value 0
Range
0 = Unknown
1 = 193-EIO-63-24D
2 = 193-EIO-43-120
3 = 193-EIO-43-240
4 = 193-EIOGP-42-24D
5 = 193-EIOGP-22-120
6 = 193-EIOGP-22-240
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
Default Value 0
Range
0 = Unknown
1 = 193/592-EIO-VIG-30A-__
2 = 193/592-EIO-VIG-60A-__
3 = 193/592-EIO-VIG-100A-__
4 = 193/592-EIO-VIG-200A-__
5 = 193/592-EIO-IG-30A-__
6 = 193/592-EIO-IG-60A-__
7 = 193/592-EIO-IG-100A-__
8 = 193/592-EIO-IG-200A-__
9 = 193/592-EIO-I-30A-__
10 = 193/592-EIO-I-60A-__
11 = 193/592-EIO-I-100A-__
12 = 193/592-EIO-I-200A-__
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
