Rockwell Automation Publication 193-UM015D-EN-P - February 2015 425
Chapter 10
Firmware Updates
Introduction
This chapter provides detailed information about firmware compatibility among
the various E300 Electronic Overload Relay modules and provides instructions
on how to update firmware for an E300 Electronic Overload Relay module.
Firmware Compatibility
The sensing, control, and communication modules of an E300 Electronic
Overload Relay have their own firmware for the functionality of the module and
its subsystems. Each module and its associated subsystems can be updated using
the ControlFLASH utility, which is the same utility that is used to download
firmware into a Logix-based controller. Table 500
shows the specific firmware
revisions for all E300 Electronic Overload Relay modules and subsystems for the
three system releases.
Table 500 - E300 System Revision Table
Table 501 shows which firmware revisions are compatible with the other E300
Electronic Overload Relay modules and their associated subsystems.
E300 System Revision 1.034 1.035 2.034 2.035 3.033 3.049
E300 Control Module
193-EIO Application
1.002 1.003 2.002 2.003 3.001 3.001
193-EIO Boot Code
1.005 1.005 1.006 1.006 1.007 1.007
193-EIO EDS Files
— — — — 3.001 3.001
E300 Communication Module
193-ECM-ETR Application
1.003 1.003 1.003 1.003 1.003 1.004
193-ECM-ETR Boot Code
2.001 2.001 2.001 2.001 2.001 2.001
193-ECM-ETR FPGA
1.008 1.008 1.008 1.008 1.008 1.008
193-ECM-ETR File System
1.001 1.001 1.001 1.001 1.001 1.002
E300 Sensing Module 193-ESM Sensing Module
1.001 1.001 2.002 2.002 2.002 2.002
