Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 355
Metering and Diagnostics Chapter 8
Table 471 - Analog Module 3 Status (Parameter 125)
Analog Module 4
Analog Module 4 – Input Channel 00
Analog Module 4 – Input Channel 00 (Parameter 120) reports the monitored
value of Analog Module 4 – Input Channel 00.
Table 472 - Analog Module 4 – Input Channel 00 (Parameter 120)
Analog Module 4 – Input Channel 01
Analog Module 4 – Input Channel 01 (Parameter 121) reports the monitored
value of Analog Module 4 – Input Channel 01.
Bit
Function
1514131211109876543210
XInput Channel 00 Open Circuit
XInput Channel 00 Over Range
XInput Channel 00 Under Range
XInput Channel 01 Open Circuit
XInput Channel 01 Over Range
XInput Channel 01 Under Range
XInput Channel 02 Open Circuit
XInput Channel 02 Over Range
XInput Channel 02 Under Range
XOutput Channel 00 Open Circuit
XOutput Channel 00 Hold Last State Mode Active
XOutput Channel 00 Over Range
XOutput Channel 00 Under Range
XAnalog Module Configured
XAnalog Module Warning (Module Number Dial Changed)
XAnalog Module Faulted
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
