Rockwell Automation Publication 193-UM015D-EN-P - February 2015 73
System Operation and Configuration Chapter 4
Analog I/O Expansion Module 2 Type (Parameter 230)
The E300 Electronic Overload Relay supports up to four additional Analog I/O
expansion modules. This parameter configures the Option Match feature for the
Analog I/O expansion module set to Analog Module 2. There is one type of
Analog I/O expansion module. Place the value of the expected Analog I/O
expansion module set to Analog Module 2 into Parameter 230. A value of (0)
disables the Option Match feature for this Analog I/O expansion module. A
value of (1), “No Analog I/O Expansion Module”, makes the Analog I/O
expansion module set to Analog Module 2 not allowed on the Expansion Bus and
prevents you from connecting an Analog I/O expansion module set to Analog
Module 2 to the E300 Electronic Overload Relay system.
Table 34 - Analog I/O Expansion Module 2 Type (Parameter 230)
Analog I/O Expansion Module 3 Type (Parameter 231)
The E300 Electronic Overload Relay supports up to four additional Analog I/O
expansion modules. This parameter configures the Option Match feature for the
Analog I/O expansion module set to Analog Module 3. There is one type of
Analog I/O expansion module. Place the value of the expected Analog I/O
expansion module set to Analog Module 3 into Parameter 231. A value of (0)
disables the Option Match feature for this Analog I/O expansion module. A
value of (1), “No Analog I/O Expansion Module”, makes the Analog I/O
expansion module set to Analog Module 3 not allowed on the Expansion Bus and
prevents you from connecting an Analog I/O expansion module set to Analog
Module 3 to the E300 Electronic Overload Relay system.
Table 35 - Analog I/O Expansion Module 3 Type (Parameter 231)
Code Description Analog I/O Expansion Module Cat. No.
0 Ignore —
1
No Analog I/O Expansion Module (Analog I/O Expansion
Module Not Allowed)
—
2 3 Universal Analog Inputs / 1 Analog Output 193-EXP-AIO-31
Code Description Analog I/O Expansion Module Cat. No.
0 Ignore —
1
No Analog I/O Expansion Module (Analog I/O Expansion
Module Not Allowed)
—
2 3 Universal Analog Inputs / 1 Analog Output 193-EXP-AIO-31
