Rockwell Automation Allen-Bradley E300

Rockwell Automation Publication 193-UM015D-EN-P - February 2015 91
System Operation and Configuration Chapter 4
Table 64 - Analog Input Data Format for Voltage Input Type
Table 65 - Analog Input Data Format for RTD Input Type
Input Range Input Value Condition
Engineering
Units
Engineering
Units x 10
Raw /
Proportional
PID
0…10 V DC
10.50V DC High Limit 10500 1050 32767 17202
10.00V DC High Range 10000 1000 32767 16383
0.00V DC Low Range 0 0 -32768 0
0.00V DC Low Limit 0 0 -32768 0
1…5 V DC
5.25V DC High Limit 5250 525 32767 17407
5.00V DC High Range 5000 500 32767 16383
1.00V DC Low Range 1000 100 -32768 0
0.50V DC Low Limit 500 50 -32768 -2048
0…5V DC
5.25V DC High Limit 5250 525 32767 17202
5.00V DC High Range 5000 500 32767 16383
0.00V DC Low Range 0 0 -32768 0
0.00V DC Low Limit 0 0 -32768 0
Input Range Input Value Condition
Engineering
Units
Engineering
Units x 10
Raw /
Proportional
PID
RTD 
100 Ω, 200 Ω,
500 Ω, 1000 Ω
Pt 385
850.0 °C High Limit 8500 850 32767 16383
850.0 °C High Range 8500 850 32767 16383
-200.0 °C Low Range -2000 -200 -32768 0
-200.0 °C Low Limit -2000 -200 -32768 0
1562.0 °F High Limit 15620 1562 32767 16383
1562.0 °F High Range 15620 1562 32767 16383
-328.0 °F Low Range -3280 -328 -32768 0
-328.0 °F Low Limit -3280 -328 -32768 0
RTD 
100 Ω, 200 Ω,
500 Ω, 1000 Ω
Pt 3916
630.0 °C High Limit 6300 630 32767 16383
630.0 °C High Range 6300 630 32767 16383
-200.0 °C Low Range -2000 -200 -32768 0
-200.0 °C Low Limit -2000 -200 -32768 0
1166.0 °F High Limit 11660 1166 32767 16383
1166.0 °F High Range 11660 1166 32767 16383
-328.0 °F Low Range -3280 -328 -32768 0
-328.0 °F Low Limit -3280 -328 -32768 0
RTD 
10 Ω Cu 426
260.0 °C High Limit 2600 260 32767 16383
260.0 °C High Range 2600 260 32767 16383
-100.0 °C Low Range -1000 -100 -32768 0
-100.0 °C Low Limit -1000 -100 -32768 0
500.0 °F High Limit 5000 500 32767 16383
500.0 °F High Range 5000 500 32767 16383
-148.0 °F Low Range -1480 -148 -32768 0
-148.0 °F Low Limit -1480 -148 -32768 0
RTD 
100 Ω Ni 618
260.0 °C High Limit 2600 260 32767 16383
260.0 °C High Range 2600 260 32767 16383
-100.0 °C Low Range -1000 -100 -32768 0
-100.0 °C Low Limit -1000 -100 -32768 0
500.0 °F High Limit 5000 500 32767 16383
500.0 °F High Range 5000 500 32767 16383
-148.0 °F Low Range -1480 -148 -32768 0
-148.0 °F Low Limit -1480 -148 -32768 0
