Rockwell Automation Publication 193-UM015D-EN-P - February 2015 45
Installation and Wiring Chapter 2
Table 7 - Short Circuit Ratings per EN60947-4-1
Table 8 - High Fault Short Circuit Ratings per UL60947-4-1 and CSA 22.2 No. EN60947-4-1 with Bul.
100-C and 100-D IEC contactors that are protected by fuses
Overload Relay with Sensing Module Cat. No.
Prospective Short-
Circuit Current, I
r
[A]
Conditional Short-Circuit
Current, I
q
[A]
Maximum Voltage [V]
193-ESM-___-30A-C23
3,000 100,000 690
193-ESM-___-30A-C55
193-ESM-___-30A-E3T
193-ESM-___-30A-P
193-ESM-___-30A-T
193-ESM-VIG-30A-CT
592-ESM-___-30A-S2
193-ESM-___-60A-C55
193-ESM-___-60A-E3T
193-ESM-___-60A-P
193-ESM-___-60A-T
592-ESM-___-60A-S2
193-ESM-___-100A-C97
5,000 100,000 690
193-ESM-___-100A-E3T
193-ESM-___-100A-T
592-ESM-___-100A-S3
Overload Relay with
Sensing Module Cat. No.
Contactor Cat. No. Max. Starter FLC [A]
Max. Available Fault
Current [A]
Max. Voltage [V] Class C or JJ fuse [A]
193-ESM-___-30A-C23
100-C09 9
100,000 600
20
100-C12 12 20
100-C16 16 30
100-C23 23 30
193-ESM-___-30A-C55, 
193-ESM-___-60A-C55
100-C30 30 50
100-C37 37 50
100-C43 43 70
100-C55 55 80
193-ESM-___-100A-C97
100-C72 72 100
100-C85 85 150
100-C97 97 200
