Sirius 800 Series User Manual Monitoring and Multiviewer Overview Multiviewer & Input/Output Monitoring Modules 13.1
Iss 5 Rev 7 Page 228 © 2017 SAM
Monitor Outputs and External Multiviewer Outputs:
Each monitor output port must be configured to match the type of signal it will be monitoring
when the router is in use (see Table 55). This configuration is carried out in Workbench, see
the Workbench manual for information.
The monitor output ports only output mono signals. If an AES left or right channel is routed to
a monitor output the relevant AES pair will be output as a combined mono signal.
Multiviewer Crosspoint:
A 5902 Multiviewer Crosspoint module is required by the External Multiviewer option and by
the MV-800 Integrated Multiviewer option.
Signal Type Monitored Monitor Output Port Configuration Required
Discrete MADI or AES Audio
4915, 4929 and 4925 modules
Configure Monitor Output Port to Matrix 2 (Audio)
Video
5917, 5919, 5926, 5938, 5949, 5913,
5914, 5915, 5916, 5923, 5924, 5925 and
5937 modules
Configure Monitor Output to Matrix 1 (Video)
Embedded audio is passed with the video signal
Table 55 Monitor Output Port Configuration
