231
1. Use the following formula to calculate the slice level:
(High level - Low level) x 0.3 + Low level = slice level
2. Tap [GAP Slice Level] in the [Calibrate] menu.
3. Change the [Gap Slice Level] value. Set the [Gap Slice Level] to the level calculated in step 1.
4.
Tap to confirm the value.
• If you set the [Gap Slice Level] to 0.0 (V), the printer sets the slice level automatically.
[I-Mark Levels]
Manually set the I-mark sensor level.
The setting procedure is as follows:
First, adjust the "Low" level (voltage) of the I-mark sensor.
1. Pass the media (attached with liner) above the I-mark sensor. Align it so that the I-mark sensor
does not detect the I-mark (black mark).
2. Close the top cover. To get the correct adjustment result, adjust after you have closed the top
cover.
3. Tap [I-Mark Levels] in the [Calibrate] menu.
4. Change the [Emit] value until the [Sensor] value is below 0.5 (V). Set the [Emit] value as low as
possible.
5. If the [Sensor] value does not decrease below 0.5 after you changed the [Emit] value, change the
[Receive] value.
6. Take a note of the [Sensor] value from the above procedure. This is the "Low" level value for the I-
mark sensor.
Next, check the "High" level (voltage) of the I-mark sensor as follows:
1. Pass the media above the I-mark sensor so that the I-mark sensor can detect the I-mark (black
mark).
2. Close the top cover.
3. Check the [Sensor] value.
If the value is 1.0 (V) higher than the "Low" level value you have recorded, this is the "High" level
value for the I-mark sensor.
If the difference between the "High" and the "Low" levels is less than 1.0, adjust the [Emit] and
[Receive] values so that the difference is more than 1.0, or adjust the "Low" level (voltage) of the I-
mark sensor again.
4.
If both "High" and "Low" levels comply with the standard value, tap to confirm the value.
The standard values for the "High" and "Low" levels for the I-mark sensor are as follows:
◦ Low (without I-mark) < 0.5 (V)
◦ High (with I-mark) - Low ≥ 1.0 (V)
[I-Mark Slice Level]
Set the I-mark sensor slice level.
To Next Page
