[Advanced]
230
• If the media is not fed correctly after [Auto-calibration], contact your SATO reseller or
technical support center.
[GAP Levels]
Manually set the Gap sensor level.
The setting procedure is as follows:
First, adjust the "Low" level (voltage) of the Gap sensor.
1. Remove the label from the liner.
2. Pass the liner above the I-mark sensor. Align it so that the I-mark sensor does not detect the I-
mark (black mark).
3. Close the top cover. To get the correct adjustment result, adjust after you have closed the top
cover.
4. Tap [GAP Levels] in the [Calibrate] menu.
5. Change the [Emit] value until the [Sensor] value is below 0.5 (V). Set the [Emit] value as low as
possible.
6. If the [Sensor] value does not decrease below 0.5 after you changed the [Emit] value, change the
[Receive] value.
7. Take a note of the [Sensor] value from the above procedure. This is the "Low" level value for the
Gap sensor.
Next, check the "High" level (voltage) of the Gap sensor as follows:
1. Pass the media (attached with liner) above the I-mark sensor. Align it so that the I-mark sensor
does not detect the I-mark (black mark).
2. Close the top cover.
3. Check the [Sensor] value.
If the value is 1.0 (V) higher than the "Low" level value you have recorded, this is the "High" level
value for the Gap sensor.
If the difference between the "High" and the "Low" levels is less than 1.0, adjust the [Emit] and
[Receive] values so that the difference is more than 1.0, or adjust the "Low" level (voltage) of the
Gap sensor again.
4.
If both "High" and "Low" levels comply with the standard value, tap to confirm the value.
The standard values for the "High" and "Low" levels for the Gap sensor are as follows:
◦ Low (with only liner) < 0.5 (V)
◦ High (media attached with liner) - Low ≥ 1.0 (V)
[GAP Slice Level]
Set the Gap sensor slice level.
The setting procedure is as follows:
