233
[Linerless Levels]
Manually set the linerless sensor level.
Appears only if the optional cutter kit or partial cutter kit is installed.
The setting procedure is as follows:
First, adjust the "Low" level (voltage) of the linerless sensor.
1. Remove the media.
2. Tap [Linerless Levels] in the [Calibrate] menu.
3. Change the [Emit] value until the [Sensor] value is below 0.5 (V).
Set the [Emit] value as low as possible.
4. If the [Sensor] value does not decrease below 0.5 after you changed the [Emit] value, change the
[Receive] value.
5. Take a note of the [Sensor] value from the above procedure. This is the "Low" level value for the
linerless sensor.
Next, check the "High" level (voltage) of the linerless sensor as follows:
1. Load the media.
2. Close the top cover.
3. Check the [Sensor] value.
If the value is 1.0 (V) higher than the "Low" level value you have recorded, this is the "High" level
value for the linerless sensor.
If the difference between the "High" and the "Low" levels is less than 1.0, adjust the [Emit] and
[Receive] values so that the difference is more than 1.0, or adjust the "Low" level (voltage) of the
linerless sensor again.
4.
If both "High" and "Low" levels comply with the standard value, tap to confirm the value.
The standard values for the "High" and "Low" levels for the linerless sensor are as follows:
◦ Low (without media) < 0.5 (V)
◦ High (media loaded) - Low ≥ 1.0 (V)
[Head Check]
Automatically check if there is a broken element of the print head.
The options are as follows:
Off
Disable the Head Check.
All
Check the entire print area.
Barcode
Check only the area for printing a barcode. Head check is not applicable for barcodes printed as
graphic data.
