[Advanced]
234
• Head check is a reference for checking for a broken element of the print head. This
function does not guarantee barcode readability. A regular barcode reader test is
required. When a void of printing got up, the head check function may not work
immediately. Some gaps may occur.
For the outputted label after the head error, perform the scanner reader of the printed
barcode to check the label.
[Head Check Mode]
Set the method for head check.
Appears only if you have selected [All] or [Barcode] in the [Head Check] menu.
The options are as follows:
Always
Perform the head check for every item.
After Batch
The head check occurs before starting to print and when printing is stopped. If backfeed is
applicable, the head check occurs before starting to print, when stopping to print and during the
backfeed.
Every Page
Perform the head check for each specified number of media.
[Every Page]
Perform the head check for each specified number of media.
Appears only if you have selected [Every Page] in the [Head Check Mode] menu.
The setting range is from 1 to 999999.
[Check Media Size]
Enable or disable media size check.
Appears only if you have selected [Gap] or [I-Mark] in the [Sensor Type] menu.
By enabling this function, "Media Error" is shown if either of the following conditions applies:
• If the media is more than 3 mm (0.12") longer than the media length specified with the media size
command ESC+A1.
• If the current media feed length is more than 3 mm (0.12") longer than the media length fed for
the first time after this function is enabled.
[Adjustments]
Correct the offset position, print position and print darkness.
The setting items are as follows:
[Offset]
Correct the offset position.
Offset adjusts the backfeed/stop position for Tear-off/Cut/Dispense operation.
