SATO FX3-LX User Manual

[Advanced]
236
[Feed After Error]
Set whether to automatically feed the media when recovering from an error and changing to Online
mode.
Feed the media when changing to Online mode after recovering from an error.
Do not feed the media when changing to Online mode after recovering from an error.
However, if [Feed At Power On] is enabled, the printer feeds the media when it is powered on and
changes to Online mode.
Also, if [Auto Measure] is enabled, the printer feeds the media when it changes to Online mode for
the first time after being powered on.
[Feed At Power On]
Set whether to automatically feed the media at power on.
Feed the media when the printer is powered on and changes to Online mode.
Do not feed the media when changing to Online mode after the printer is powered on.
Also, if [Auto Measure] is enabled, the printer feeds the media when it changes to Online mode for
the first time after being powered on.
[Finisher Feed]
Set the media feed amount for Tear-off, cut and dispense stop. Set the media feed amount based on
the print head position of 0.
The actual media feed amount is the value of [Offset] + [Finisher Feed].
The setting range is from 0 to 3060 dots.
• The length of 1 dot is 0.083 mm (0.0033").
• You can change the unit to dots or inches in the [System] > [Regional] > [Unit] menu.
[Paper End]
Select the sensor for sensing the paper end.
The options are as follows:
Using I-mark
Use the I-mark sensor (reflective type) to detect the paper end.
Using Gap
Use the Gap sensor (transmissive type) to detect the paper end.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
