SATO FX3-LX User Manual

241
Auto
Automatically generate the IP address and gateway (stateless mode).
DHCP
Automatically retrieve the IP address and gateway from the DHCP server (stateful mode).
Static
Manually set the IP address, gateway and prefix length.
[DHCP] (USB+LAN Model Only)
Update the lease time and get the IP address from the DHCP server again.
Appears only if you have selected [DHCP] in the [Mode] menu.
[IP Address] (USB+LAN Model Only)
Set and check the IP address.
If you have selected [DHCP] in the [Mode] menu, the screen shows the IP address you received from
the DHCP server.
If you have selected [Static] in the [Mode] menu, set the IP address.
The setting range is as follows:
0:0:0:0:0:0:0:1 to ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff
[Prefix Length] (USB+LAN Model Only)
If you have selected [Static] in the [Mode] menu, set the prefix.
The setting range is from 1 to 128.
[Gateway] (USB+LAN Model Only)
Set and check the default gateway address.
If you have selected [DHCP] in the [Mode] menu, the screen shows the gateway address you received
from the DHCP server.
If you have selected [Static] in the [Mode] menu, set the default gateway address.
The setting range is as follows:
0:0:0:0:0:0:0:0 to ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff
• The gateway address set here is shared with the settings in [Wi-Fi] > [Wi-Fi Setting] >
[IPv6 (Wi-Fi)].
[DNS] (USB+LAN Model Only)
If you have selected [Static] in the [Mode] menu, set the primary address of the DNS server.
The setting range is as follows:
0:0:0:0:0:0:0:0 to ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff
• You can register only one IP address for the DNS server for IPv6.
• The DNS server addresses set here are shared with the settings in [Wi-Fi] > [Wi-Fi
Setting] > [IPv6 (Wi-Fi)].

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
