283
Japanese, Chinese, and Korean only support a change in the layout of the keyboard.
The IME (Input Method Editor) is not compatible, so you cannot input hiragana,
katakana, or kanji.
[Locale]
Set the locale to be used in AEP (Application Enabled Printing) mode.
This setting determines the format of time, dates, numbers, prices, names of weekdays, months, etc.
in AEP applications.
Select the locale from the list.
[On-Screen Keyboard]
Set the language for the on-screen keyboard.
[Unit]
Set the unit of length for indication.
The options are as follows:
[dot]
["] (inch)
[mm]
[Time]
Set the time.
1.
Set the current time by tapping / , and then tap .
2.
On the confirmation message, tap to cancel, or tap to confirm the setting.
[Date]
Set the date.
1. Set the current date by tapping the date on the calendar.
2.
On the confirmation message, tap to cancel, or tap to confirm the setting.
[Time Zone]
Set the time zone.
First select the region from the map.
Then select the city from the list.
[Display Language Icon]
Set whether to display the [Language] icon on the top screen of the [Settings] menu.

Table of Contents

Other manuals for SATO FX3-LX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO FX3-LX and is the answer not in the manual?

SATO FX3-LX Specifications

General IconGeneral
CutterYes
CertificationEN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodesAZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID moduleNo
Maximum resolution- DPI
Maximum print height500 mm
Maximum printing width80 mm
Battery voltage14.4 V
AC input voltage100 - 240 V
Battery capacity1950 mAh
AC input frequency50 / 60 Hz
Suitable for use in country/locationEurope
Sustainability certificatesENERGY STAR
DisplayLCD
Control typeTouch
Product colorWhite
Display diagonal7 \
Display resolution480 x 800 pixels
International Protection (IP) codeIPX2
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
USB 2.0 ports quantity4
Connectivity technologyWired & Wireless
Media thickness0.14 - 0.19 mm
Maximum roll diameter105 mm
Storage temperature (T-T)-5 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 75 %
Cables includedAC
Quantity per pack1 pc(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width132 mm
Height180 mm
Weight3000 g
