SATO FX3-LX User Manual

[Help]
308
Continuous/Tearoff
Shows the video for loading the media roll to the printer to print in continuous/tear-off mode.
Dispenser
Shows the video for loading the media roll to the printer to print in dispenser mode.
Cutter/Partial Cutter
Shows the video for loading the media roll to the printer to print in cutter/partial cutter mode.
Linerless tearoff
Shows the video for loading the media roll to the printer to print in linerless tearoff mode.
Linerless cutter
Shows the video for loading the media roll to the printer to print in linerless cutter mode.
[Fanfold]
Shows the video for loading the fan-fold media.
[Cradle]
Shows the video for installing the printer on the optional cradle kit.
The items are as follows:
AC
Shows the video for installing the standard printer on the optional cradle kit.
Battery
Shows the video for installing the printer with the optional battery mount kit on the optional cradle
kit.
[WLAN Option]
Shows the video for installing the optional wireless LAN/Bluetooth kit to the printer.
[Replace Head]
Shows the video for replacing the print head.
[Replace Platen]
Shows the video for replacing the platen roller.
[Replace Battery]
Shows the video for replacing the optional battery.
[Replace Battery Kit]
Shows the video for installing the optional battery mount kit.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
