About the Base Reference Point
376
I-mark Position or Gap Base Reference Point
Gap label
(1) Feed direction
(2) Print position
Tear-Off Mode
I-mark Position or Gap Base Reference Point
Center I-mark
Bottom I-mark
Top I-mark
Custom I-mark (Labels with I-marks other than
our specifications)
This I-mark position is an example.
