Replacing the Optional Linerless Platen Roller
434
7. Install the new linerless platen roller (7) and turn the two levers (8) backward.
8. Tilt the two tabs (6) of the feed roller inside to set the feed roller.
9.
Make sure that the tabs are parallel to the both sides of the printer ( ) and the two
rollers rotate in an interlocked manner ( ).
