9. Solenoid Valve and Pressure Transducer
STATIM 2000/2000S/2000 G4 Service Guide
Figure 7
1. Pressure Interface Board
2. Power switch
3. Line cord (not shown)
4. Printer cable
5. Cable tie
6. Armature
7. Transducer connector
8. Transducer
9. Transducer wires
10. Ejector latches
11. Controller Board
12. Battery
1
2
4
4
5
6
78
9
9
10
11
12
