11. Steam Generator, Check Valve, Thermal Fuse and Pressure Relief Valve
1. Turn the power switch OFF, and unplug the unit. Remove cover.
2.
a. For all controller boards other than revision 7.x — Remove the pressure interface
board or printer cable (if fitted) from the blue socket and disconnect the steam generator
thermocouple wires (1) from Controller Board (2) terminal positions BOILER +Y and -R and
disconnect the ground lead terminal (3) from the position marked BOILER directly above
the terminals. Leave the screws with contact washers in the terminals.
b. For revision 7.x controller boards — disconnect the chamber thermocouple plug from the
socket on the controller board.
3. Disconnect the black thermal fuse (4) wire from controller board connector terminal block
J1-3.
4. Trace the path of the black wire back to the base of the steam generator (5). Carefully cut all
cable ties holding the black wire.
5. Carefully cut the cable ties (6) securing the steam generator thermocouple lead (8) and other
wires to the armature (11).
6. Disconnect the white wire (12) attached to the terminal on the lower half of the steam
generator.
7. On units where a compressor is fitted, carefully cut the cable tie (13) holding the compressor
tube (14) onto the check valve inlet (15) and pull the tube off the valve.
8. Disconnect the compression nut (16) holding the Teflon™ tube (17) from the top of the steam
generator.
9. Disconnect the compression nut (18) holding the steam generator outlet tube (19) to the steam
generator outlet fitting (20).
10. Disconnect the compression nut (21) holding the steam generator outlet tube to the probe
bracket inlet fitting (22).
11. Remove the two screws (23) holding the steam generator bracket assembly (24) to the chassis
and remove the steam generator.
Reinstalling the Aluminium Steam Generator
(for both 1st generation and Alex versions)
NOTE: DO NOT use this section when REPLACING or UPGRADING older 1st generation
aluminium steam generators to the newer Alex type. These instructions apply only to RE-
INSTALLING an aluminium steam generator (including Alex) that has been removed.
Instructions for UPGRADING to the Alex steam generator vary depending on the status of the unit
that is being upgraded (i.e., what controller and software revisions it has) and may also change
from time to time. For the most up to date procedures concerning an upgrade, use the matrix in
Figure 2 to find the appropriate kit number and follow the instructions included with the kit.
To reinstall the steam generator, proceed as follows (see Figure 3):
1. Make sure the power switch is OFF, and the unit is unplugged.
2. Place the steam generator in to position.
3. Connect the compression nut (18) holding the steam generator outlet tube (19) to the top
of the steam generator outlet fitting (20) and the compression nut (21) holding the steam
generator outlet tube to the probe bracket inlet fitting (22). Thread the nuts and finger tighten,
then tighten with a wrench. Do not over tighten.
