SciCan Statim 2000 - Calibration Cassette; Digital Voltmeter

Page 82
STAT IM 2000/2000S Service Guide
96-108639 Rev 3.0
4. STAT IM 2000 Calibration
9
10
5
1. Control box
2. Controller board
3. SELECT knob
4. Digital voltmeter
5. VRH potentiometer
6. Calibration cassette
7. Thermocouple
8. Digital thermometer
9. TC-CHM potentiometer
10. TC-BLR potentiometer
Figure 1
1234
6
7
8
STATIM 2000/2000S/2000 G4 Service Guide
