12. Printer and Data Logger
Transferring data from the USB drive or SD card
9 pin revision 7.x units only
Files are stored on the MSD in txt and PDF format. These can be transferred for storage on a
computer hard drive as follows:
1. Ensure the LCD screen of the STATIM reads “SAFELY REMOVE MSD <> MSD/FLASH
DETECTED” and the STATIM is in standby. THE UNIT MUST NOT BE RUN WHEN REMOVING
THE MSD.
2. Remove MSD from the Data Logger. The STATIM LCD screen should now show the following:
3. Insert the MSD in the relevant port on the computer and wait until the computer has recognised
the new device (if transferring for the first time).
4. The contents of the MSD should now be available for viewing in the appropriate application (e.g.
Windows Explorer).
5. Locate, or create the preferred folder for storing the data.
6. Data can now be transferred by either:
a. Drag and Drop
b. Cut and Paste
c. Copy and Paste (if you wish to retain the data on the MSD)
7. Safely ‘eject’ the MSD as appropriate to your computer and remove the MSD.
8. Re-insert the MSD back in to the Data Logger.
9. After a few seconds the STATIM LCD display should now show the following:
10. The STATIM and Data Logger are now ready for use.
HH:MM DD/MM/YYYY
“MSD NOT DETECTED”/”INSERT
MSD/FLASH”/”SELECT A CYCLE”
HH:MM DD/MM/YYYY
USB/FLASH DETECTED/SAFELY
REMOVE MSD/SELECT A CYCLE
