Page 56
STAT
IM
2000/2000S Service Guide
96-108639 Rev 3.0
3. Troubleshooting Cycle Faults
Changes to the threshold value may be changed as follows:
1. The UNWRAPPED button will increase the selected value and the WRAPPED cycle button will
decrease it.
2. To move to the next value, press the RUBBER / PLASTIC button.
3. To save changes and return to the regular operating mode, press the STOP button. The
changes will be saved automatically.
4. To quit without making changes, power the STATIM OFF.
>Water.Cnd Tmp. Comp
Screen display when in Water.Cnd Tmp. Comp sub menu.
Electrical conductivity can change with temperature and as a result provide a false reading
possibly causing the unit to show a water quality/level fault when the water is in fact good. To
overcome this, revision 7 STATIM units have water conductivity temperature compensation built in
to the software to overcome this potential problem.
The default setting on all STATIM units is ON. To change this (NOT recommended) or to reset this
condition should it change as a result of a software or controller change, follow these steps:
1. The UNWRAPPED or WRAPPED keys will switch the screen display to “ON” or “OFF”
depending on the opening display.
2. The RUBBER & PLASTICS key will save the change and return the unit to the service menu.
3. Pressing the STOP key will exit without saving and return the unit to the operational menu.
>Stored CF Printouts
When this function is activated, this sub menu will send saved Cycle Faults to a printer or SciCan
Data Logger. The unit will then default back to the normal operational menu.
Note that the saved CF printouts will ONLY be sent to the printer or Data Logger when either one
is attached and configured.
The following types of errors are saved:
t$ZDMF'BVMUT$'
t8BUFSRVBMJUZPS8BUFSMFWFMMPXFSSPST
t$ZDMFJOUFSSVQUFEEVFUPFSSPST
Pressing the STOP key will exit and return the unit to the operational menu.
>Clear CF Printouts
Screen display when in Clear CF Printouts sub menu.
This function will reset the cycle fault list. The options are “YES” (clear the list) or “NO” (do not
clear the list.
STATIM 2000/2000S/2000 G4 Service Guide
>Water.Cnd Tmp. Comp
On
>Clear CF Printouts
No
