3. Troubleshooting Cycle Faults
STATIM 2000/2000S/2000 G4 Service Guide
CF
No.
Unit
type
Software revision
Description of Fault
Probable Cause (or causes) of Fault
S Non
S
1.xx/
2.xx
4.xx 5.xx 6.xx/
7.xx
30
The cassette temperature failed to reach the
sterilization temperature within 15 seconds of
the theoretical cassette temperature calculated
from the measured cassette pressure reaching
the sterilization temperature.
% Poor air removal during conditioning
(exhaust blockage).
% Calibration imbalance (pressure
transducer or chamber thermocouple)
% Blockage or restriction in pressure
transducer tube
31 - 49
Not used
50
For the Rubber and Plastics cycle, the chamber
temperature dropped below the sterilization
temperature, allowing for measurement error
(i.e. Tchm < 121°C).
% Poor air removal during conditioning
(exhaust blockage).
% Not able to generate steam
%
Steam leak in the system
51
For the Rubber and Plastics cycle, the chamber
temperature rose more than 4 C° above the
sterilization temperature, allowing for
measurement error (i.e. Tchm > 125°C).
% Sticking solenoid valve (closed)
% Failed solenoid coil
% Blocked cassette exhaust duct
% Obstructed exhaust tubing (kink)
52
For the Rubber and Plastics cycle, the
theoretical chamber temperature as calculated
from the measured chamber pressure was more
than 2°C below the measured chamber
temperature, allowing for measurement error.
% Calibration imbalance (pressure
transducer or chamber thermocouple)
% Sticking solenoid valve (closed)
% Failed solenoid coil
% Blocked cassette exhaust duct
% Obstructed exhaust tubing (kink)
% Poor air removal
53
For the Rubber and Plastics cycle, the
theoretical chamber temperature as calculated
from the measured chamber pressure was more
than 2°C above the measured chamber
temperature, allowing for measurement error.
% Calibration imbalance (pressure
transducer or chamber thermocouple)
% Sticking solenoid valve (closed)
% Failed solenoid coil
% Blocked cassette exhaust duct
% Obstructed exhaust tubing (kink)
% Poor air removal
