Operating instructions Distance measuring device DL100 – CANopen®
Operation via Ethernet (Ethernet interface)
Field"MF1Functionconguration" Requirements for the display
• Parameter "MF1 activation": Option "Enable"
Parameter Description
Function Select function for multifunction input and output MF1.
Read/Write access
• Read and write
Input value
• 0: Distance: → Seepage66,eld"MF1,Thresholddis-
tanceunderow"
• 1: Velocity: → Seepage66,eld"MF1,Thresholdvelocity
exceeded"
• 2: Service: → Seepage67,eld"MF1,Servicecongura-
tion"
• 3: Laser
• 4: Preset
Factory setting
• Distance
Active condition Select level for the active condition for the multifunction input
and output MF1.
Read/Write access
• Read and write
Input value
• 0: high / 1: low
Factory setting
• Low
Table 36: Page “Parameter settings” – eld “MF1 Function conguration”
