Field"MF2Functionconguration" Requirements for the display
• Parameter "MF2 activation": Option "Enable"
Parameter Description
Function Select function for the multifunction MF2 output.
Read/Write access
• Read and write
Input value
• 0: Distance / 1: Velocity / 2: Service
Factory setting
• Service
Active state Select level for the active condition for the multifunction
output MF2.
Read/Write access
• Read and write
Input value
• 0: high / 1: low
Factory setting
• Low
Table 40: Page "Parameter settings" – eld "MF2 Function conguration"
Field "MF2, Threshold distance
underow"
→Seepage66,Table37,"MF1,Thresholddistanceunderow"
Field "MF2, Threshold velocity
exceeded"
→ See page 67, Table 38, "MF1, Threshold velocity exceeded"
Field"MF2,Serviceconguration" →Seepage67,Table39,"MF1,Serviceconguration"
Field "Number of MF activation"
Parameter Description
MF1 Counts the switching events of the multifunction input and
output MF1. You may reset the counters via the button "Reset
MF1".
Read/Write access
• Read and write
Input value
• –2147483648 ... 2147483647
M2 Counts the switching events of the multifunction output MF2.
You may reset the counters via the button "Reset MF2".
Read/Write access
• Read and write
Input value
• –2147483648 ... 2147483647
Table 41: Page "Parameter settings" – eld "Number MF activation"
