Overview
1.4 System components and accessories
ITC V3, ITC V3 PRO
Operating Instructions, 03/2024, A5E42761061-AF
31
Extension Unit box
The Extension Unit box offers an empty enclosure for installation of larger customer-specific
components below a 16:9 SIMATIC PRO device for pedestal (extendable, flange bottom) or
for support arm (extendable, round tube).
The Extension Unit is supplied without operator controls; the front has not been prepared for
installation of operator controls. The Extension Unit box is available in four sizes:
• Extension Unit box 12", article number 6AV7674-1LA30-0AA0
• Extension Unit box 15", article number 6AV7674-1LA40-0AA0
• Extension Unit box 19", article number 6AV7674-1LA50-0AA0
• Extension Unit box 22", article number 6AV7674-1LA60-0AA0
• Extension Unit box 24", article number 6AV7674-1LA70-0AA0
You can find the associated documentation on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109761025).
Handles
The width of the handles can be adjusted so that the entire device can be aligned or
positioned without having to touch the display of the PRO device.
Article number: 6AV7674-1LB10-0AA0
You can find the associated documentation on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109761024).
Keyboard tray
You can mount the keyboard tray plate or a matching keyboard to the keyboard tray. In
addition, the keyboard tray has two openings for USB interfaces on the front and two
openings for cable glands in the rear.
Article number: 6AV7674-1NF01-0AA0
You can find the associated documentation on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109761024).
