System description
SIMOCODE pro
1-88 GWA 4NEB 631 6050-22 DS 03
Reading out the device-internal event memory
The "Event Memory" menu item enables access to the SIMOCODE pro
device-internal event memory. The two most recent events "DM-F enabling
circuit closed" and "DM-F enabling circuit open" are displayed, together with
the time, for both digital modules "DM-F Local" and "DM-F PROFIsafe".
Table 1-18: Reading out the device-internal event memory
Switch to event memory display.
Last event "Enabling circuit closed",
DM-F Local,
The entry contains the last event "DM-F enabling circuit closed", the
time and the related DIP switch configuration.
Note
Only available if digital module 1 is DM-F Local.
Last event "Enabling circuit closed",
DM-F PROFIsafe
The entry contains the last event "DM-F enabling circuit closed", the
time and the related PROFIsafe address.
Note
Only possible if digital module 1 is DM-F PROFIsafe.
Last event "Enabling circuit opened"
The entry contains the last event "DM-F enabling circuit open" and
the corresponding time.
Note
Only available if digital module 1 is DM-F Local or
DM-F PROFIsafe.
