System description
SIMOCODE pro
1-102 GWA 4NEB 631 6050-22 DS 03
Documentation for safety-oriented functions and failsafe digital
modules
Safety-oriented functions and additional information on failsafe digital
modules can be found in the following documentation:
System manuals and operating manuals are available at:
www.siemens.com/industrial-controls/manuals.
The failsafe digital module DM-F Local provides safety-oriented tripping of
a motor feeder via a hardware signal that is detected and evaluated by the
module.
From a non-safety-oriented perspective, the DMF comprises:
Table 1-24: Inputs, outputs and voltage supply of the digital module
Failsafe Local (DM-F Local)
The failsafe digital module DM-F PROFIsafe provides safety-oriented
tripping of a motor feeder by a failsafe control (F-CPU) via PROFIBUS with
the failsafe PROFIsafe profile.
From a non-safety-oriented perspective, the DM-PROFIsafe comprises:
Documentation
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY " (German)
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY" (English)
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY" (French)
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY" (Spanish)
Operating manual "Failsafe digital module DM-F Local"
Operating manual "Failsafe digital module DM-F PROFIsafe"
Inputs Supply
1
) Outputs
4 digital inputs (non-safety-oriented):
- Input 1: Sensor circuit
- Input 2: Start input
- Input 3: Feedback circuit
- Input 4: Cascade input
24 V DC 2 monostable relay outputs
inputs (non-safety-oriented)
