System description
SIMOCODE pro
1-110 GWA 4NEB 631 6050-22 DS 03
Object Manager OM SIMOCODE pro
SIMOCODE pro Object Manager OM is part of SIMOCODE ES. When
SIMOCODE ES and SIMOCODE OM pro are installed on a PC/PD,
SIMOCODE ES can be called up directly from STEP 7 HW Config. This
enables simple and complete SIMATIC S7 configuration.
SIMOCODE pro PCS 7 Library
The SIMOCODE pro PCS 7 function block library is used to simply and
conveniently connect SIMOCODE pro to the SIMATIC PCS 7 process
control system. The SIMOCODE pro PCS 7 function block library contains
the diagnostic and driver blocks that correspond to the diagnostic and driver
concept of SIMATIC PCS 7 and the elements (symbols and faceplates)
necessary for operating and monitoring. Integration is carried out graphically
with the CFC editor.
Signal processing and technological functions of the SIMOCODE pro PC7
function block library are oriented towards the SIMATIC PCS 7 standard
libraries (Driver Blocks, Technological Blocks) and are optimized for
SIMOCODE pro. Users that have previously configured motor feeders
conventionally via Signal Blocks or Motor/Solenoid Valve Blocks can easily
switch to the SIMOCODE pro PCS 7 function block library.
The SIMOCODE pro PCS 7 function block library supplied on CD-ROM
enables the user to use the required engineering software on one
engineering station (single license) including the runtime software to run AS
blocks in one automation system (single license). If the AS blocks are used
in additional automation systems, an appropriate number of runtime
licenses is required (these are delivered without CD).
Note
The PCS 7 libraries are subject to continual maintenance and improvement.
Current Service Packs and Hotfixes can be downloaded at
http://www.siemens.com/simocode -> Support -> Software Downloads.
Notice
Observe the respective system versions!
GSD File
For integration into SIMATIC S7 or any standard DP master system
(automation system). The latest version can be found on the internet
at
http://www.siemens.com/profibus-gsd.
Further information on integrating DP slaves can be found in the automation
system documentation.
Win SIMOCODE DP converter
This is a software tool for converting "old" Win SIMOCODE DP parameter
files (3UF5 device series) into SIMOCODE ES parameter files for
SIMOCODE pro.

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
