Motor protection
SIMOCODE pro
3-4 GWA 4NEB 631 6050-22 DS 03
Adjustable responses "Overload Protection", "Unbalance Protection" and "Stalled
Rotor Protection"
Table 3-1: Responses for "Overload Protection", "Unbalance Protection" and "Stalled Rotor Protection"
See also "Tables of responses of SIMOCODE pro" in
Chapter "Important information".
Notice
Deactivate Unbalance Protection in SIMOCODE ES when the load type is
set to single-phase!
Response At prewarning
level
At trip level level
"Unbalance"
"Stalled Rotor
Protection" level
Deactivated X X X X
Signaling X X X X
Warning X
XX X
Tripping - X XX
Delay 0-25.5 s (0.5 s) - 0-25.5 s (0.5 s) 0-25.5 s (0.5 s)
