Siemens SIMOCODE pro System Manual

Motor protection
SIMOCODE pro
3-16 GWA 4NEB 631 6050-22 DS 03
• Sensor fault (sensor circuit error):
Here you can select the SIMOCODE pro response in the case of a short
circuit or an open circuit in the thermistor sensor cable.
Table 3-2: "Thermistor Protection, Binary" response
See also "Tables of responses of SIMOCODE pro" in Chapter "Important
information".
Response Trip level Sensor fault
Deactivated - X
Signaling X X
Warning X X
Tripping X X

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
