Siemens SIMOCODE pro

System description
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
1-3
Fig. 1-1: SIMOCODE pro integrated in the main circuit, control circuit and at automation level (PLC)
Control circuit Automation levelMain circuit
Connecting cable
Current measuring module
Basic unit
Operator panel
Remote
Protection + Monitoring
(overload, thermistor, earth-fault …)
Control circuit
(including monitoring + interlocks)
Communication
(operating, service and diagnostics data
+ control commands)
