Siemens SIMOCODE pro System Manual

Motor control
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
4-43
Settings
You will find detailed information about the settings in:
Chapter 4.2.2 "General settings and definitions".
Dahlander
reversing starter
Description
ON << ON << control command (LEFT, FAST)
(connection with arbitrary socket ,
usually with "Enabled control command - ON <<" socket)
ON < ON < control command (LEFT, SLOW)
(connection with arbitrary socket ,
usually with "Enabled control command - ON <" socket)
OFF OFF control command
(connection with arbitrary socket ,
usually with "Enabled control command - OFF" socket)
ON > ON > control command (RIGHT, SLOW)
(connection with arbitrary socket ,
usually with "Enabled control command - ON >" socket)
ON >> ON >> control command (RIGHT, SLOW)
(connection with arbitrary socket ,
usually with "Enabled control command - ON >>" socket)
FB ON Auxiliary control input "Feedback ON"
(connection with arbitrary socket ,
usually with "Status - Motor current flowing" socket)
Non-maintained
command mode
•
Deactivated
• Activated
Saving change-over
command
• Deactivated
• Activated
Separate failsafe
function from
control function
• Deactivated:
Safety-oriented tripping via the DM-F module also affects the
SIMOCODE pro control function, so that additional fault
messages are avoided.
This setting is selected for applications where safety-oriented
tripping directly affects the motor controlled by SIMOCODE pro.
• Activated:
Safety-oriented tripping via the DM-F module does not affect the
SIMOCODE pro control function.
This setting is selected for applications where safety-oriented
tripping does not affect the motor controlled by SIMOCODE pro.
Load type You can choose between:
•
Motor
• Resistive load (see Chapter 4.2.2 "General settings and
definitions")
Feedback time Range 0 - 25.5 seconds (0.5 s
)
Execution time Range 0 - 6553.5 seconds (1.0 s
)
Interlocking time Range 0 - 255 seconds (0 s)
Change-over pause Range 0 - 655.3 seconds (10 ms increments) (0.00 s
)
Table 4-13: Control function settings for Dahlander reversing starter

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
