Monitoring functions
SIMOCODE pro
5-14 GWA 4NEB 631 6050-22 DS 03
Trip level, warning level
With active power monitoring, you can parameterize two different response
levels (trip level/warning level) for the upper and lower limit.
Trip level and warning level activity
The trip level/warning level is only effective when the motor is running, the
start-up procedure has been completed and there is no test position
feedback (TPF) (run+).
Response when trip level P> (upper limit), P< (lower limit)
Here you can set how SIMOCODE pro should respond if the set trip level is
either undershot or overshot:
See also "Tables of responses of SIMOCODE pro" in Chapter "Important
information".
Table 5-11: "Trip level" response for active power monitoring
Response when warning level P> (upper limit), P< (lower limit)
Here you can set how SIMOCODE pro should respond if the set warning
level is either undershot or overshot:
See also "Tables of responses of SIMOCODE pro" in Chapter "Important
information".
Table 5-12: "Warning level" response for active power monitoring
Trip l eve l
• P> (upper limit)
• P< (lower limit)
0.000
- 4294967.295 kW
Warning level
• P> (upper limit)
• P< (lower limit)
0.000 - 4294967.295 kW
Response Trip level
Deactivated X
Signaling X
Warning -
Tripping X
Delay 0 - 25.5 s (0.5 s
)
Response Warning level
Deactivated X
Signaling X
Warning X
Tripping -
Delay 0 - 25.5 s (0.5 s
)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
