Monitoring functions
SIMOCODE pro
GWA 4NEB 631 6050- 22 DS 03
5-23
Trip level and warning level activity
The trip level/warning level always takes effect, independent of whether the
motor is running or not (operating status "ON").
Response
See also "Tables of responses of SIMOCODE pro" in Chapter "Important
information".
• Overtemperature: Here you can select how SIMOCODE pro should respond
when the temperature has overshot the warning level/trip level.
Table 5-17: "Overtemperature" response
Notice
With motors for EEx e applications, the response must be set to "Tripping"!
Note
The sensor type, the number of measuring circuits in use and the response
to a sensor fault must be set in the "Temperature Module Inputs (TM
Inputs)" function block if temperature monitoring is being used.
Note
To monitor several sensor measuring circuits individually and independently,
a suitable number of free limit monitors can be linked to the "Temperature
Module Inputs (TM Inputs)" function block and differing limits set for the
individual temperature sensors, instead of the "Temperature Monitoring"
function block.
Response Warning level T> Trip level T>
Deactivated X -
Signaling X X
Warning X
-
Tripping - X
