Outputs
SIMOCODE pro
6-10 GWA 4NEB 631 6050-22 DS 03
Application examples
• Controlling the motor contactor in the motor feeder
You can define which relay output is to be used for controlling the main
contactor in the motor feeder.
For this, connect the desired relay output to the respective "QE" contactor
control of the control function.
• Controlling lamps for displaying operating states:
You can define which relay outputs are to be used for controlling the lamps/
LEDs that display the operating states of the motor (Fault, ON, OFF, Fast,
Slow...).
For this, connect the desired relay output to the respective "QL..." lamp
control of the control function.
• Transfer of any other information, status information, warnings, faults, etc. to
the relay outputs.
In many cases, the outputs of the digital module will be connected to the
QE outputs. By referring to Table 4-21 on page 4-65 you can determine
which QE outputs are required for which control functions.
Settings
Defaults depend on the selected application (template): See Chapter E
"Example circuits".
"DM1/DM2
Outputs"
Description
Outputs 1 to 2 Control of the "DM1 Outputs" and "DM2 Outputs" function blocks
with any signal
(any sockets ,
e.g. device inputs, control bits from PROFIBUS DP, etc.
usually from the QE contactor controls)
Table 6-4: "DM1/DM2 Outputs" settings
