Siemens SIMOCODE pro System Manual

Outputs
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
6-17
Cyclic services
Cyclic Send Data is exchanged once in every DP cycle between the DP
master and the DP slave. The DP master sends the cyclic receive data to
SIMOCODE pro. In response, SIMOCODE pro sends the cyclic send data to
the DP master.
Settings
Cyclic Send Data Description
Byte 0 to 1
Bit 0 to bit 7
Basic types 1*, 2
Control of bits with any signals
(any sockets
e.g. device inputs, Send Data, etc.)
Byte 2/3
Basic types 1*, 2
Control of one word (two bytes) with any analog values
(any sockets
e.g. maximum current I_max, remaining cooling down period,
actual value of timers, etc.)
Byte 4/5, 6/7, 8/9
Basic type 1*
Control of three words (six bytes) with any analog values
(any sockets )
Table 6-6: Cyclic Send Data settings
*) For basic unit 2 only
Byte 0 of the Send Data is already preset. Byte 2/3 is preset with the max.
current I_max!
See also Chapter 12.4 "Telegram description and data access".

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
