Inputs
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
7-5
Application examples
The inputs can be used, for example, for connecting the start and stop
buttons of the local control station, which can then be assigned to the "Local
Control Station" function block.
If assigned accordingly, the input signals can also be used to activate
function blocks such as "Reset" or "External Fault".
Supplying the inputs
See Chapter 13.2.1 "Basic units, expansion modules and the decoupling
module".
Settings
Basic unit Description
Delay time
Inputs
You can set a delay time for the inputs, if required.
Range: 6, 16
, 26, 36 ms
Table 7-2: "Basic unit inputs" settings
