Siemens SIMOCODE pro System Manual

Inputs
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
7-13
Application examples
Among other things, you can monitor the following motor components:
• Motor windings
• Motor bearings
• Motor coolant temperature
• Motor gearbox oil temperature.
The individual temperatures of the three sensor measuring circuits can be
monitored independently of each other by connecting free limit monitors.
Settings
Table 7-6: Temperature module input settings
1)
Table 7-7: "Sensor fault/Out of range" response
See also "Tables of responses of SIMOCODE pro" in Chapter "Important
information".
Temperature module Description
Sensor type PT100
, PT1000, KTY83, KTY84, NTC
Response
1)
at sensor fault/
Out of range
Deactivated, signaling, warning, tripping
Number of active sensors 1 sensor, 2 sensors, 3 sensors
Response Sensor fault/Out of range
Deactivated X
Signaling X
Warning X
Tripping X
Delay -

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
