Siemens SIMOCODE pro System Manual

Standard functions
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
10-13
Settings
Safety guidelines
Note
A "Trip - Operational protection OFF (OPO)" fault message is not generated if
the "OPO" command attempts to run the positioner to the end position in
which it is already in, or to which it is heading.
Note
No other control command (counter command or stop command) is carried
out while "Operational protection OFF (OPO)" is active.
Note
The "Trip - Operation protection OFF (OPO)" fault message must be
acknowledged using the open or closed control command, depending on
the present "OPO" end position.
Note
Acknowledgement is carried out even if the desired end position has not yet
been reached.
Note
The fault message is available as diagnosis via PROFIBUS DP.
Operational
protection OFF
(OPO)
Description
Input Control of the "Operational Protection OFF" function block using the
monitored signal (any sockets ,
e. g. device inputs etc.)
Positioner
response
Specification of the response for the "Positioner" control function
when activated via the input:
• CLOSED: Positioner moves to the "Closed"
end position.
• OPEN: Positioner moves to the "Open" end position.
Type Specification of the input logic
• NO contact (1-active)
• NC contact (0-active)
Table 10-9: Operational protection OFF settings

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
