Siemens SIMOCODE pro System Manual

Logic modules
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
11-5
Circuit and parameterization
Fig. 11-4: Example circuit and parameterization for truth table 3I/1O
Settings
Truth tables 1-6 3I/
1O -
Description
Input 1 to 3 Activate the truth table with any signal
(any sockets
e.g. device inputs, control bits from PROFIBUS DP, etc.)
Table 11-2: Settings for truth table 3I/1O
S2
S3
S1
Circuit:
1
2
Out1
3
Truth Table 1 3I/1O
Input 1
Input 2
Input 3
Output
1
2
3
4
L1
N
BU
Connect inputs, i.e.
Connecting plugs with sockets
Set bits for
Parameterization with SIMOCODE ES
output signals
Q1
BU Inputs
BU Outputs

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
