System description
SIMOCODE pro
1-18 GWA 4NEB 631 6050-22 DS 03
Safety-oriented tripping
The SIMOCODE pro V motor management system has been extended by 2
modules/safety relays for the safety-oriented tripping of motors:
• Failsafe digital module DM-F Local:
For applications that require the safety-oriented tripping of a motor feeder via
a hardware signal that is detected and analyzed by the module.
• Failsafe digital module DM-F PROFIsafe:
For applications that require the safety-oriented tripping of a motor feeder by
a failsafe control (F-CPU) via PROFIBUS with the failsafe PROFIsafe profile.
These modules fulfill the general requirements for EMERGENCY STOP
mechanisms or safety circuits, as described in the standards EN 418 and
EN 60204-1 (06/2006).
Depending on the external circuit, the following Performance Level/Safety
Integrity Level can be achieved:
• PL e Category 4 according to ISO 13849-1 or
• SIL 3 according to IEC 61508/62061.
Safety technology and safety-oriented functions:
• Are limited exclusively to failsafe digital modules.
• Do not directly affect existing SIMOCODE pro components and concepts.
A more detailed description is provided in the documentation listed below:
System manuals and operating manuals are available at:
www.siemens.com/industrial-controls/manuals.
Caution
Use a power supply unit compliant with IEC 60536, Class III (SELV or PELV)!
A suitable safety circuit is required for capacitive and inductive loads!
Documentation
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY " (German)
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY" (English)
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY" (French)
System manual "Failsafe Digital Modules SIMOCODE pro SAFETY" (Spanish)
Operating manual failsafe digital module DM-F Local
Operating manual failsafe digital module DM-F PROFIsafe
