Identification-related diagnostics - definition
Identification-related diagnostics begins at byte 6 and is 2 bytes long.
Identification-related diagnostics - configuration
Fig. 12-4: Configuration of identification-related diagnostics
Status information - definition
The status information provides the detailed status of SIMOCODE pro.
If SIMOCODE pro is operated downstream from the Y-link (module for
connecting single-channel DP slaves to S7-400H), the so-called H_STATUS is
also signaled (see Fig. 12-6 "H_STATUS configuration").
0 1 0 0 0 0 1 0
765 0
Byte 6
Bit number
= 0x42
Length of identification-related diagnostics
including byte 6 (= 2 bytes)
Code for identification-related diagnostics
0 0 0 0 0 0 0 x
765 0
Byte 7
Bit number
0: Identification-related diagnostics is not available
1: Identification-related diagnostics is available
0 0 0 0 00 0x
765 0
Byte 7
Bit number
0: Identification-related diagnostics is not available
1: Identification-related diagnostics is available
GSD
OM SIMOCODE pro
