Mounting, wiring, interfaces
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
13-3
Mounting lugs for screw attachment
Notice
For technical reasons, there are two different mounting lugs for the screw
attachment:
For basic units, expansion modules,
and the decoupling module: Order no. 3RP1903
For current measuring modules,
and current/voltage measuring modules.
45 mm and 55 mm width: Order no. 3RP1900-0B
Removable terminals
Notice
The removable terminals are mechanically coded and will only fit in a certain
position!
