Commissioning and service
SIMOCODE pro
14-10 GWA 4NEB 631 6050-22 DS 03
Saving parameters from the memory module into the basic unit
Note
This function will not be available if the Test/Reset button has been blocked.
Proceed as follows:
Table 14-7: Saving parameters from the memory module into the basic unit
Notice
If the memory module is plugged in, the parameters will be transferred from
the memory module to the basic unit when the supply voltage is switched
on.
Saving parameters from a SIMOCODE ES file into the basic unit
Proceed as follows:
Table 14-8: Saving parameters from a SIMOCODE ES file to a basic unit
Step Description
1 Plug the memory module into the system interface. The "Device" LED lights up
yellow for approx. 10 seconds. During this time, briefly press the "TEST/
RESET" button. The parameters will be transferred to the basic unit. After
successful data transfer, the "Device" LED flickers yellow for approx.
3 seconds.
2 If necessary, unplug the memory module from the system interface.
Step Description
1 Plug the PC cable into the system interface.
2 Start SIMOCODE ES.
3 Click on the menu Switchgear > Open. The parameters from the
SIMOCODE ES file will be transferred to the main memory.
4 Click on the menu Target system > Load into switchgear. The parameters
will be saved into the basic unit from the main memory.
