Siemens SIMOCODE pro System Manual

Tables
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
A-13
1) S7 format: 0/4 mA=0
20 mA=27648
35 Last trip current 1 % / Is IM UM
36 TM - Max. temperature 1K TM
37 TM - Temperature 1 1K TM
38 TM - Temperature 2 1K TM
39 TM - Temperature 3 1K TM
40 Permissible starts - Actual value BU1 BU2
41 Motor stop time 1h BU1 BU2
42 DM-F - Time until test required 1 week DM-F
43 Reserved
44 AM - Input 1 See 1) AM
45 AM - Input 2 See 1) AM
46 Reserved
47 Reserved
48 Acyclic Receive - Analog value BU1 BU2
49 Cyclic Receive - Analog value BU2
50 Reserved
51 Reserved
52 Motor operating hours - H word
1s
BU1 BU2
53 Motor operating hours - L word BU1 BU2
54 Int. motor operating hours - H word BU1 BU2
55 Int. motor operating hours - L word BU1 BU2
56 Device operating hours - H word BU1 BU2
57 Device operating hours - L word BU1 BU2
58 Number of starts - H word BU1 BU2
59 Number of starts - L word BU1 BU2
60 Int. number of starts right - H word BU1 BU2
61 Int. number of starts right - L word BU1 BU2
62 Int. number of starts left - H word BU1 BU2
63 Int. number of starts left - L word BU1 BU2
64 Reserved
.. Reserved
69 Reserved
70 Active power P - H word
1W
BU2
71 Active power P - L word BU2
72 Apparent power S - H word
1VA
BU2
73 Apparent power S - L word BU2
75 Reserved
.. Reserved
255 Reserved
No. Designation Unit Information
Table A-4: Socket assignment table - analog (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
