Data formats and data records
SIMOCODE pro
B-2 GWA 4NEB 631 6050-22 DS 03
Data records - overview
Table B-1: Data records - overview
Data record No. Description Read/write
1 S7 system diagnostics Read
63 Analog value recording Read
67 Process image of the outputs Read
69 Process image of the inputs Read
72 Error buffer Read
73 Event memory Read
92 Device diagnostics
(faults, warnings, status information)
Read
94 Measured values Read
95 Service/statistical data Read/write
130 Basic device parameters 1 (BU1 BU2) Read/write
131 Basic device parameters 2 (BU1 BU2) Read/write
132 Extended device parameters 1 (BU2) Read/write
133 Extended device parameters 2 (BU2) Read/write
139 Marking Read/write
160 Communication parameters Read/write
165 Identification Read/write
202 Acyclic receive Read/write
203 Acyclic send Read
224 Password protection Write
