Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-7
Byte
Bit
DR0 DR1 Designation Type No error Error Information
8.4 X Overload Bit 0 0
8.5 X Overtemperature Bit 0 0
8.6 X Open circuit Bit 0 0
8.7 X Upper limit overshot Bit 0 0
9.0 X Lower limit undershot Bit 0 0
9.1 X Error Bit 0 X Error F9
9.2 X Reserved Bit 0 0
9.3 X Reserved Bit 0 0
9.4 X Reserved Bit 0 0
9.5 X Reserved Bit 0 0
9.6 X Reserved Bit 0 0
9.7 X Reserved Bit 0 0
10.0 X Parameterization error Bit 0 X Error F16
10.1 X Sensor or load voltage missing Bit 0 0
10.2 X Fuse defective Bit 0 0
10.3 X Reserved Bit 0 0
10.4 X Earth fault Bit 0 0
10.5 X Reference channel fault Bit 0 0
10.6 X Process alarm missing Bit 0 0
10.7 X Actuator warning Bit 0 0
11.0 X Actuator trip Bit 0 0
11.1 X Safety-oriented tripping Bit 0 0
11.2 X External fault Bit 0 0
11.3 X Non-specific error Bit 0 0
11.4 X Reserved Bit 0 0
11.5 X Reserved Bit 0 0
11.6 X Reserved Bit 0 0
11.7 X Reserved Bit 0 0
12.0 X Reserved Byte[4] 0 0
Table B-3: Data record 0/1 - S7 system diagnostics (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
